Features
- x8 Upstream Port
- PCIe express cable interface from host
- Up to 10 feet of cable from host
- Currently uses 12x Infiniband cable to transmit x8 PCIe express Interface and side band signals
- Successor products will be offered with PCI-SIG specified PCIe express cables (when ratified)
- Eight PCI Express Downstream Ports
- Two x8 PCIe Express Slots
- Six x4 PCIe Express Slots using x8 connectors
- Two 32 Lane PCI Express Switches supporting:
- Peer-to-Peer Communications
- Non-Blocking Switch Fabric
- Data Integrity
- Quality of Service
- Hot Plug support for all eight expansion slots
- Attention Button
- Attention LED
- Power LED
- ATX Form Factor
- Interfaces to PCI-X-402 PCI-X Slot to cable adapter or PCIe-401 PCIe express slot to cable adapter
- Available Desktop or Rackmount Chassis (Additional)
- 400W Power Supply
- RoHS Compliant
- PCIe-411 PDF Data Sheet
|
600-2704 Block Diagram |
